RANGE OF EXPERIMENTS TO BE CARRIED OUT:
- To Study the Effect of speeds and feeds on the action of cutting tool.
- To Study the Effect of Mechanical properties of work material on cutting forces.
- To observe the Values of forces exerted on machine components on jigs and fixtures, and effect of these forces on the geometrical accuracy of the work pieces.
TECHNICAL DESCRIPTION :
This is a armed wheel type strain gauge drill tool dynamometer designed to measure thrust & torque during drilling operation. This dynamometer is suitable for drilling a hole up to 25 mm size in Mild Steel. With this dynamometer students can study the change in these forces by varying speed, Cut & feed.
DIMENSIONS AND WEIGHT :
Size :0.3 m.(L)x 0.3 m(W) X 0.3m ( H )
Weight : Approx. 5 Kg
SERVICE REQUIRED :
Power Supply : 230 v Ac Supply 50 Hz
SCOPE OF DELIVERY:
- Experimental Setup
- Instructional Manual
OPTIONAL FACILITY: Data logging Facility
