RANGE OF EXPERIMENTS TO BE CARRIED OUT:
- To study all components/Accessories used in Steam Boiler.
- To determine Boiler Efficiency with & without economizer at different Steam pressure.
- To determine Equivalent evaporation.
- To determine the overall and individual film heat transfer coefficients for a condensation of a vapour on a Surface condenser.
- To Determine Mach Number of Steam Nozzle & Steam Diffuser.
TECHNICAL DESCRIPTION :
This setup consists of Non IBR Boiler of suitable capacity assembled with steam economizer, condenser and water softener. Temperature at different locations are measured by using thermocouple. A pump is provided for circulation of water to the condenser. An entire unit if fixed on frame with necessary steam piping .
DIMENSIONS AND WEIGHT :
Size :8.5 m.(L)x 6.5 m(W) X 3.0m ( H )for boiler
Size :4.0 m.(L)x 2.0 m(W) X 1.5m ( H ) for cooling pond
Weight :Approx. 1500 Kg
SERVICE REQUIRED :
- Power Supply : 440v, AC ,Three Phase , 50HZ
- Diesel : 200 Ltr.
- Tap water supply @50 lpm
- RCC CONSTRUCTION FOR COOLING POND
SCOPE OF DELIVERY:
- Experimental Setup
- Instructional Manual
