TECHNICAL DESCRIPTION :
The apparatus consists of two rafter struts and a restraining tie mounted on a self contained, bench top base Both struts and tie incorporate linear, direct reading spring balances to measure forces
Loading at the hinged apex by load hanger
The tie length, and hence angle of truss, variable
Struts and tie re-adjustable to original lengths
DIMENSIONS AND WEIGHT :
Size : 0.5 m.(L)x 0.3 m(W) X 0.5 m ( H )
WEIGHT : Approx. 3 Kg
SCOPE OF DELIVERY :
- Experimental Setup
- Instructional Manual
