TECHNICAL DESCRIPTION :

Specifications

• Magnification: 30X
• Resolving Power: 3″
• Minimum Focus: 1.7 m
• Field of View: 2.7m/100m
• Non-reflectorless distance measurement from 1 to 2.700m
• Distance accuracy (2 + 2ppm x Dist)mm
• 5"/ 1,5mgon angle accuracy
• Telescope with 30x magnification
• Pre-installed, versatile survey programs enhance work efficiency in the field an operator to to perform a wide variety of survey tasks with ease.
• The SET510K control panel features a backlit, 10-key alphanumeric keypad equiped on both faces of the instrument.
• Password function prevents unauthorized use of the instrument
• Supreme dust and water resistance compliant with IP66
• 10,000 point internal memory
• Distance measurment on prism and reflective sheets
• Li-Ion battery (BDC46A) for 7,5 continuous measurements
• This instrument comes standard in instrument case including BDC46 Li-Ion battery and CDC86 Charger (round pin).
• Optional items for this instrument are:
• SF14 wiresless keyboard; 37 keys (including alphanumeric, softkeys and measurement controls) to enable quick and easy data entry
• DE25 diagonal eyepiece

DIMENSIONS AND WEIGHT :

Size ::0.5 m.(L)x 0.5 m(W) X 0.5 m ( H )

WEIGHT : Approx. 15 Kg
