DESCRIPTION :

The equipment consists of Borosilicate glass round bottom flask as distillation still. The distillation is carried out by using steam. The vapors coming from the column is going in to the condenser. The distillate is collected in round bottom flask.

RANGE OF EXPERIMENTS TO BE CARRIED OUT :

• To study the simple steam distillation.
• To calculate the steam required for the distillation.

EXPERIMENTAL SETUP :

• Reboiler : Borosilicate glass round bottom flask
• Distillate Receiver : Borosilicate glass round bottom flask
• Condenser : Borosilicate glass double pipe condenser
• Steam Generator : Electrically heated baby boiler with Pressure gauge, Safety Valve
• Digital Temp Indicator : 0 – 400 0 C
• Temp Sensor : CR/AL Type
• Pump : FHP Submersible pump
• Piping : PVC
• Setup Mounting : On sturdy MS stand with powder coated

SERVICE REQUIRED :

Power Supply : 230V, 50Hz, A. C

CHEMICALS REQUIRED:

Turpentine

SPACE REQUIRED :

1.5 m. ( L) x 1.0 m (W) X 0.7 m (H).

WEIGHT : @ 55 Kg
