RANGE OF EXPERIMENTS TO BE CARRIED OUT :

• To study the Fluidised bed drying Process .
• To calculate the rate of drying.

TECHNICAL DESCRIPTION :

The apparatus consists of glass shell with roller supports at the two ends & a gear connected to the motor. Wet feed is fed through the chute & dried product outlet point. Air is supplied by a blower. By pass valve & flow control blower enable variation of air flow rate through the drier. heating arrangement for air heating is provided measures air flow rate. Thermometer measures the temperature of wet feed & dried product. Wet & dry built thermometers enable measurement of air condition at inlet to & outlet from the counter flow rotary drier. The rotational speed of shell is evaluated by measuring the speed of rotation of motor & the gear ratio or by visual observation of a colored water on the shell & by turning the number of revolution with the help of s stop clock.

DIMENSIONS AND WEIGHT :

Size : 2.5 m.(L)x 1m(W) X 1.5m ( H )
Weight : Approx. 100 Kg

SERVICE REQUIRED :

Power Supply : 230 v Ac Supply 50 Hz

SCOPE OF DELIVERY:

• Experimental Setup
• Instructional Manual
