RANGE OF EXPERIMENTS TO BE CARRIED OUT:

• To Study the performance of Centrifugal pump in Parallel.
• To calculate the efficiency of pump in Parallel.
• To plot graph of Discharge v/s Head.
• To plot graph of Input Power v/s Head.
• To plot graph of Efficiency v/s Head.

TECHNICAL DESCRIPTION :

The apparatus consists Centrifugal pump of suitable capacity connected in Parallel.Suction and discharge pressure are measured by using vacuum and pressure gauge respectively.Flow through pump is controlled by using discharge control valve.Discharge though the pump is measured by using measuring tank. Sump Tank of suitable capacity is provided.Energy meter is provided for measurement of power consumption of pump.This system is complete closed circuit type and easy to move due to wheels.

DIMENSIONS AND WEIGHT :

Size :1.5 m.(L)x 1.0 m(W) X 1.5m ( H )
Weight :Approx. 100 Kg

SERVICE REQUIRED :

Power Supply:230 v Ac Supply 50 Hz

Water :100 ltr

SCOPE OF DELIVERY:

• Experimental Setup
• Instructional Manual
