RANGE OF EXPERIMENTS TO BE CARRIED OUT:

• To Study the Electrical Analogy of water flow.

TECHNICAL DESCRIPTION :

The experimental set up consists of a transparent tank of suitable size. In this tank the model under study is to be installed. The model is to be designed as per the requirement out of copper and Bakelite plates. A sample model arrangement will be given with the setup. A probe is mounted on a trolley, which can traverse in two planes fitted on. Tray to locate equipotential lines. X – y co – ordinate of the probe at each be locate on the scale fitted on the cross slide. Necessary potential can be given with the help of analogue field plotter can be displayed on the meter provided.

DIMENSIONS AND WEIGHT :

Size :0.5 m.(L)x 0.5 m(W) X 0.3m ( H )
Weight :Approx. 10 Kg

SERVICE REQUIRED :

Power Supply:230 v Ac Supply 50 Hz

Water :10 ltr

SCOPE OF DELIVERY:

• Experimental Setup
• Instructional Manual
