RANGE OF EXPERIMENTS TO BE CARRIED OUT :
- To study the Angular Displacement Measurement using Electromagnetic Pickup.
TECHNICAL DESCRIPTION :
Here a small motorized Set Up is provided. Motor output speed is controlled using a typical Dimmer type arrangement. The electromagnetic sensor is provided for measurement of speed. This input will be processed using RPM Indicator.
DIMENSIONS AND WEIGHT :
Size : 0.5 m.(L)x 0.5m(W) X 0.4m ( H )
Weight : Approx. 5 Kg
SERVICE REQUIRED :
Power Required : 230 v AC Single Phase.
SCOPE OF DELIVERY:
- Experimental Setup
- Instructional Manual
